12.3 Inch TFT-LCM
Product Description
12.3 Inch TFT LCD
Suitable for smart home, industrial instrumentation, e-sports games
product description of 12.3Inch TFT LCD
Resolution 1920 x 720 pixels, high brightness IPS Projected Capacitive Touch (PCAP) TFT-LCD module, can support 2 LVDS (Low-Voltage-Differential-Signaling) interfaces, using LVDS (Low-Voltage-Differential-Signaling) technology in TFT displays are becoming more and more popular. This technology is suitable for TFT LCD modules that require high-speed data transfer. LVDS (Low Voltage Differential Signaling) is a low-voltage differential signaling mode. It provides high data transfer rates with very low power consumption. Consumption has many benefits.
Specifications of 12.3 Inch TFT LCD
|
Contents |
Description |
|
Display outline size |
308.1 mm (H ) x 130.0 mm ( V ) x 15.0 mm ( D ) |
|
VA size |
292.032 mm ( H ) x109.512 mm ( V ) |
|
Resolution |
1920 RGB ( H ) x 720 ( V ) |
|
With /Without Touch screen |
CTP |
|
Interface |
2Port LVDS |
|
Pixel Pitch |
0.1521(H)x 0.1521 mm ( V ) |
|
Color |
16.7M |
|
Luminance |
Typ 850 nits |
FAQ of 12.3 Inch TFT LCD
Q:Are you a manufacturer?
A: We are an LCD manufacturer with 15 years of professional LCD manufacturing experience
Q:Can you provide samples?
A: We can provide samples, but you need to pay the sample fee
Q: How about the delivery time?
A: Generally, it is 15 days, depending on the material and quantity of the product you ordered. We will give you the exact time after placing the order.
Q：Do you accept customization?
A: We can accept custom LCD.
